Main functions

Dual Frequency Display, Dual Independent Operation System

Eight Bands for Receiving, Four Bands (Including SW) for Transmitting

Twin Band / Same Band Simultaneous Reception

999 Memory Channel

Front Panel And Radio Body Flexible For Separation

QT/DOT Encoding And Decoding

QT/DOT Scanning

Non-standard CTCSS/DCS Setting Freely

Same Band Repeat on Two Combined Radios

Dual Track And Multi-way Loudspeakers

Hand Microphone DTMF With Loudspeakers

Caller ID Display

DTMF Encoding And Decoding

Multiple Scanning Ways

Group Calls, All Calls And Selective Calls

8 Groups of Scrambler

Priority Channel Scanning

APO Power Management

Wide / Narrow Bandwidth Selectable

Chinese or English Voice Guide

Automatic Temperature Detection

Stun / Kill Function

Single Audio Pulse Frequency

Multiple Back Light Color Selectable

Scan Channel Adding / Deleting

Grouping Channel Scanning

Multiple Setting for Cooling Fan

Technical specifications

Frequency Range (suitable for different countries or areas, programmable by software):
TX FM standard: 28-29 MHz / 50-52 MHz / 144-146 MHz / 430-440 MHz
TX FM after modification (export): 26-30 MHz / 50-54 MHz / 136-174 MHz / 400-480 MHz
RX FM: 26-29.995 MHz / 50-54.995 MHz / 65-108 MHz / 108-180.995 MHz / 320-349.995 MHz / 400-479.995 MHz / 700-987.995 MHz
RX AM: 108-136 MHz

Step: 5KHz / 6.25KHz / 10KHz / 12.5KHz

25KHz / 50KHz / 100KHz

Channel Number: 999

Work Mode: F2D/F3E

Operating Temperature: -20C / +60C

Voltage: 13.8VDC (+/- 15% max)

Antenna Impedance: 50 Ohm

Weight: 1438 gram

Size: 140 x 44 x 207 mm

Receiver

Adjacent Channel Selectivity: wide >70dB / narrow >60dB

Inter Modulation: wide >65dB / narrow >60dB

Spurious Response: wide ?70dB / narrow ?70dB

Audio Response: wide +1~-3dB(0.3~3KHz) / narrow +1~-3dB(0.3~3KHz)

Signal to Noise Ratio: wide ?45dB / narrow ?40dB

Audio Distortion: <5%Audio Power: transceiver >3w / hand microphone >1w

Sensitivity UHF/VHF: 0.25µV (12dB SINAD)

Transmitter

Adjacent Channel Power: wide >70dB / narrow >60dB

Type of Modulation: wide 16K F3E / narrow 11K F3E

Spurious: wide ?60dB / narrow ?60dB

Signal to Noise Ratio: wide ?40dB / narrow ?36dB

Audio Response: wide +1~-3dB(0.3~3KHz) / narrow+1~-3dB(0.3~3KHz)

Output Power: VHF (5W/10W/25W/50W) / UHF (5W/10W/25W/40W)

Package includes:

Wouxun KG-UV980 radio

Wouxun MMO-003 hand microphone

Inclined switchboard panel

Flat switchboard panel

Mounting bracket

Remote front panel bracket

Front panel extension cable

Power DC cord

Screw sets + microphone holder

2x extra fuses

WOUXUN PROGRAMING CABLE KG-UV920 / KG-UV950 / KG-UV980

Key Specifications/Special Features:

Functions:

Wide/narrow band (25/12.5kHz)

CTCSS encode/decode

V + U/V + V/U + U dual-band operating

Cross-band repeat

Quad-band operating frequency: 27-29/50/144/430MHz

DCS encode/decode

809 memory channels

COMP function

DTMF-ANI/5 tone-ANI function2/5 tones

AM mode for aeronautical band (108-118MHz)

Automatic power-off

Display brightness setting

Hyper memory (store complete radio configuration)

Specifications:

Type: amateur HF/VHF/UHF transceiverFrequency range:
• TX: 27/28.0-29.7/50-54/144-146/430-440MHz (Europe)TX: 28.0-29.7/50-54/144-148/430-450MHz (USA)RX: 28.0-29.7/50-54/108-180/320-480MHz (5/10/12.5/15/20/25/50KHz steps)
Modes:

TX: FM/NFMRX: AM/FM/NFM

RF power output: Hi: 50/50/50/35W

Mid1: 20/20/20/20W

Mid2: 10/10/10/10W

Lo: 5/5/5/5W

Receiver system:

Double conversion super-heterodyne

1st IF: 46.05 MHz (left band), 47.25MHz (right band)

2nd IF: 450kHz

Sensitivity: <0.2uV (12dB Sinad)

Selectivity: FM: 12kHz (-6dB), 30kHz (-60dB)

Image rejection: N/A

Voltage: 13.8V

DCCurrent drain: RX: 500mA (squelched)

TX: 8.5A (maximum)

Impedance: 50Ω SO-239

Dimensions (W x H x D): 140 x 42 x 168mm

Weight: 1kg

Manufactured: China, 2012 - 201x

Others: 809 memories. CTCSS/PL and DCS. DTMF-ANIBuilt-in scrambler

Compare this one with FT-8900R

CRT-Micron ist ein sehr kompaktes Amateurfunkgerät mit allen wichtigen Funktionen. Besonders auffallend ist das farbige TFT-Display und die sehr kompakte Bauform.Das CRT Micron U/V bietet drei schaltbare Ausgangsleistungen (5/15/25 Watt) im VHF- und UHF-Bereich.
Die Bedienung erfolgt über die Linken und Rechten Funktionstasten neben dem Display,

Technische Daten

Frequenzbereich TX (Sender)

144-146 / 430-440 MHz

Frequenzbereich RX (Empfänger)

144-146 / 430-440 MHz

Sendeleistung

VHF 5W / 15W / 25W

UHF 5W / 15W / 20W

Betriebsarten

FM (TX/RX)

Kanalraster

2,5 /  5 /  6,25 /  10 /  12,5 / 20 /  25 / 30 /  50 kHz

Speicherkanäle

200

Merkmale & Funktionen

Kanalabstand 12,5, 20 und 25 kHz schaltbar

beleuchtete Tasten, um auch in Dunkelheit leichte Bedienung zu ermöglichen

gut ablesbares TFT-Display (mehrfahrbig) mit Anzeige Frequenz, Empfangssignal, Ausgangsleistung, Betriebsspannung, Funktionsanzeigen uvm.

Betriebsart FM  (breit und schmal schaltbar)

gleichzeitiger Betrieb VHF/UHF, UHF/VHF, UHF/UHF  oder VHF/VHF möglich

schaltbare Tonruf-Frequenzen 1000 Hz/1450 Hz/1750 Hz/2100 Hz

schaltbare Relaisablage +/- mit wählbarer Differenzfrequenz

CTCSS und DCS  De- und Encoder, mit 52 CTCSS und 1024 DCS-Tönen

DTMF-Sendefunktion

Zweikanalüberwachung ( Dual Watch)

Sendezeitbegrenzung einstell-/abschaltbar

CTCSS  und DCS- Suchlauf-Funktion

Suchlauf ( Scan)

Reverse-Funktion

Per optionaler PC-Software/USB-Kabel programmierbar (nicht zwingend erforderlich)

Mikrofonanschluss

Western

Antennenanschluß

PL-259 Buchse

Spannungsversorgung

13,8 V DC (max. 10 - 12 A)

Abmessungen in mm (BxHxT)

122x35x165

Gewicht

ca. 480g

Lieferumfang

CRT MICRON Transceiver

DTMF-Handmikrofon mit Lautsprecher, Bandanzeige und programmierbaren Funktionstasten

Mikrofonhalterung

DC-Kabel

Anleitung

Gewicht: 0.48 kg

Main functions

Dual Frequency Display, Dual Independent Operation System

Eight Bands for Receiving, Four Bands (Including SW) for Transmitting

Twin Band / Same Band Simultaneous Reception

999 Memory Channel

Front Panel And Radio Body Flexible For Separation

QT/DOT Encoding And Decoding

QT/DOT Scanning

Non-standard CTCSS/DCS Setting Freely

Same Band Repeat on Two Combined Radios

Dual Track And Multi-way Loudspeakers

Hand Microphone DTMF With Loudspeakers

Caller ID Display

DTMF Encoding And Decoding

Multiple Scanning Ways

Group Calls, All Calls And Selective Calls

8 Groups of Scrambler

Priority Channel Scanning

APO Power Management

Wide / Narrow Bandwidth Selectable

Chinese or English Voice Guide

Automatic Temperature Detection

Stun / Kill Function

Single Audio Pulse Frequency

Multiple Back Light Color Selectable

Scan Channel Adding / Deleting

Grouping Channel Scanning

Multiple Setting for Cooling Fan

Technical specifications

Frequency Range (suitable for different countries or areas, programmable by software):
TX FM standard: 50-52 MHz / 70-77 MHz / 144-146 MHz / 430-440 MHz
TX FM after modification (export): 50-54 MHz / 70-77 MHz / 140-170 MHz / 420-470 MHz
RX FM: 50-54.995 MHz / 70-77 MHz / 108-180.995 MHz / 320-349.995 MHz / 400-479.995 MHz / 700-987.995 MHz
RX AM: 108-136 MHz

Step: 5KHz / 6.25KHz / 10KHz / 12.5KHz

25KHz / 50KHz / 100KHz

Channel Number: 999

Work Mode: F2D/F3E

Operating Temperature: -20ºC + 60ºC

Voltage: 13.8VDC (±15% max)

Antenna Impedance: 50 Ohm

Weight: 1438 gram

Size: 140 x 44 x 207 mm

Receiver

Adjacent Channel Selectivity: wide >70dB / narrow >60dB

Inter Modulation: wide >65dB / narrow >60dB

Spurious Response: wide >70dB / narrow >70dB

Audio Response: wide +1~-3dB(0.3~3KHz) / narrow +1~-3dB(0.3~3KHz)

Signal to Noise Ratio: wide >45dB / narrow >40dB

Audio Distortion: <5%

Audio Power: transceiver >3w / hand microphone >1w

Sensitivity UHF/VHF: 0.25µV (12dB SINAD)

Transmitter

Adjacent Channel Power: wide >70dB / narrow >60dB

Type of Modulation: wide 16K F3E / narrow 11K F3E

Spurious: wide >60dB / narrow >60dB

Signal to Noise Ratio: wide >40dB / narrow >36dB

Audio Response: wide +1~-3dB(0.3~3KHz) / narrow+1~-3dB(0.3~3KHz)

Output Power: VHF (5W/10W/25W/50W) / UHF (5W/10W/25W/40W)

Package includes:

Wouxun KG-UV980 radio

Wouxun MMO-003 hand microphone

Inclined switchboard panel

Flat switchboard panel

Mounting bracket

Remote front panel bracket

Front panel extension cable

Power DC cord

Screw sets + microphone holder

2x extra fuses

The Vero VGC VR-N7500 is a 50 Watt VHF/40 Watt UHF Headless ham transceiver. The VR-N7500 needs a smartphone or tablet as control panel so you can use all features of this radio. The main radio can be installed in the trunk while the phone/tablet is connected to the radio through Bluetooth.

Multiple Bluetooth Connections
Connect to bluetooth PTT
Connect to bluetooth speaker microphone
Connect to cell phone to programming the radio
Connect to other bluetooth 2.0+ accessories

Global Walkie Talkie / Network Radio (Android Only)
Create a network channel in app and then invite friends to the same Channel, no matter where they are, as long as they a mobile phone or a walkie-talkie with a VERO N series, you can contact in real time.

Cross Band Repeater From Network Channel To Analog) (Android Only) )
Dedicated Android app you can crossband repeat from Analog to Network and Network to Analog when the "Relay Function" has been enabled on the app.

APRS Function
The APRS feature you can send your location in real time to the APRS-IS servers, which will then plot your position on APRS maps.

Key Features
Output Power: 50 Watts VHF 40 Watts UHF
App programming
CTCSS/DCS/DTMF/2Tone, 5Tone decode and encode.
Supplied with wired mic.
Allows Multi Bluetooth connections
Allows Network radio to RF connection


In the box:
VR-N7500 Transceiver
Speaker microphone with cable
Power cable, 2x2.5mm², 3m long
Mounting bracket
One page manual

Features

Working Mode: Full duplex on UU, UV, VV,VU. Dual RX (Analog + DMR or Analog + Analog)

True-2-slot: Provide 2-slot communication which allows for 2 talk paths on 1 frequency; ETSI DMR Tier I and II compliant

Power: VHF 60W/25W/10W; UHF 50W/25W/10W

Auto-senses digital or analog reception

4000 channels + VFO; 10,000 Talk groups with 200,000 digital contacts

Support Contact Manager

Display: 1.77 inch TFT color LCD, dual display; dual PA; dual PTT

Bandwidth: 12.5K/25K (Analog); 12.5K (DMR);

Weather Alerts

VOX Function; Digital Recording and Play

DTMF/2TONE/5TONE encode and decode

AES256 digital encryption; Zone selection

SMS via keyboard

Crossband repeater function

Ranging function between radios with GPS

Roaming function; Talker alias function

Emergency alarm (with GPS data transmission)

IP connect to Motorola Repeater

Duplexer Talk(Optional)

Call interrupt(Optional)

General

Frequency Range: 144-146 / 430-440 MHz

Channel Capacity: 4000 channels

Channel Spacing: 25KHz (Wide Band), 12.5KHz (Narrow Band)

Phase-locked Step: 5KHz, 6.25KHz

Operating Voltage: 13.8V DC ±20%

Frequency Stability: ±2.0 ppm

Operating Temperature: -20ºC / +55ºC

Transmitter

Power Output: VHF: 50/25/10/5W / UHF: 45/25/10/5W

Modulation limit: ±5.0KHz@25KHz (Wide Band) / ±2.5KHz@12.5KHz (Narrow Band)

Adjacent Channel Power: >70dB (Wide Band) / >60dB (Narrow Band)

Hum & Noise: >40dB (Wide Band) / >36dB (Narrow Band)

Spurious Emission: >70dBc (Wide Band) / >70dBc (Narrow Band)

4FSK Digital Modulation: 12.5KHz (data) 7K60FXD / 12.5KHz (data + voice) 7K60FXE

Audio Distortion: <5%

Error rate: <3%

Receiver

Sensitivity (12dB SINAD): <0.25µV (Wide Band) / <0.35µV (Narrow Band)

Digital Sensitivity: 0.3µV/-117.4dBm (BER 5%) / 0.7µV/-110dBm (BER 1%)

Adjacent Channel Digital Sensitivity Selectivity: >70dB (Wide Band) / >60dB (Narrow Band)

Spurious Emission: >-57dB (Wide Band) / >-57dB (Narrow Band)

Spurious Rejection: >70dB (Wide Band) / >70dB (Narrow Band)

Blocking: 84db

Hum & Noise: >45dB (Wide Band) / >40dB (Narrow Band)

Audio Distortion: <5%

Audio Power Output: >2W

Inside the box:

Transceiver

Microphone

Mounting bracket + screws

DC power cable with fuse holder + fuses

Free PC USB program cable

Free Bluetooth PTT button

Free GPS antenna

English user manual

ORIGINAL MADE BY ALINCO, JAPAN

Dualband 2m/70cm Amateur Mobilfunkgerät inkl. Flugfunkfunk Empfang in AM

Die Hintergrundbeleuchtung des Display ist individuell programmierbar und kann mehrere Farben gleichzeitig darstellen.

Technische Daten

Frequenzbereich TX (Sender): 144-146 / 430-440 MHz

Frequenzbereich RX (Empfänger): 144-146 / 430-440 MHz

Sendeleistung:5W / 20W / 50W (VHF)

                          5W / 20W / 50W (UHF)

Mittlere Sendeleistung (MID) per Menü individuell programmierbar

Betriebsarten

FM / NFM / F1E (Digital Option) / F2D (1200bps)

AM (nur RX)

Kanalraster: 5 / 6.25 / 8.33 / 10 / 12.5 / 15 / 20 / 25 / 30 / 50 kHz / 100 kHz

Speicherkanäle: 1000 (alphanumerisch bis 6 Zeichen)

Merkmale & Funktionen:

Bedienteil abnehmbar (Separationskit EDS-30 als Option erhältlich)

Relaisablage individuell programmierbar

Tonruf programmierbar (1750 Hz / 2100 Hz / 1450 Hz / 1000 Hz)

CTCSS & DCS Funktion

DTMF Geber

Scan Funktion in verschiedenen Varianten (inkl. CTCSS & DCS Scan)

LC-Display mit mehrfarbiger Hintergrundbeleuchtung (dimmbar und Konstrast regelbar)

S-Meter im Display integriert

Mikrofonverstärkung regelbar (Mic Gain +/- 23dB)

ATT Abschwächer Funktion

Monitor Funktion

Time-Out Timer Funktion

BCLO Funktion

Pager Funktion

Unterdrückung von Empfangsstörungen durch starke Sender auf Nachbarkanälen (image signal rejection)

Tastatursperre schaltbar

Individuell programmierbare Taste (short cut key)

Zwei Buchsen zum Anschluss von Zusatzlautsprechern (3.5mm)

6-pin DIN Buchse zum Anschluss eines externen TNC (max. 4800 bps TX / max. 9600 bps RX)

Reset Funktion

Mikrofonanschluss: Western

Antennenanschluß: PL-259 Buchse

Spannungsversorgung: 13,8 VDC +/-15% (TX max. 12A / RX 0.4A)

Abmessungen in mm BxHxT: Gerät mit Bedienteil 144 x 60 x 188

                                          Gerät ohne Bedienteil: 134 x 39 x 180

Gewicht: ca. 1.3 kg

Lieferumfang:

ALINCO DR-735 Transceiver

DTMF Handmikrofon EMS-79

Mikrofonhalterung

Mobilhalterung ADFM-78

DC-Kabel UA-0038Y

Anleitung

Schaltplan
Gewicht: 1.3 kg

VHF Monoband-Mobilfunkgerät mit sensationell kleinen Abmessungen !

Aufgrund des Minigehäuse hat das Gerät eine maximale Sendeleistung von 17 Watt.

Technische Daten:

Frequenzbereich 136-174 MHz

199 Speicherplätze (per PC PC programmierbar)

Sendeleistung umschaltbar Low: 5 Watt / Middle: 10 Watt / High: ca. 15 - 17 Watt

Betriebsart FM (wide / narrow umschaltbar 16K0F3E / 11K0F3E)

CTCSS / DCS

Kanalraster wählbar 2.5 / 5 / 6.25 / 10 / 12.5 / 20 / 25 / 30 / 50 / kHz

programmierbare Relaisablage

Rauschsperre regelbar (10 Empfindlichkeitsstufen)

Monitorfunktion

Scan Funktion (inkl. CTCSS & DCS Scan)

BCLO Funktion

Time-Out Timer Funktion

APO Funktion

Mikrofon-Verstärkung regelbar (Mic Gain Setup)

Reset Funktion

Mikrofonanschluss: Mikrofon fest mit Gerät verbunden

PL-Antennenanschluss

3.5mm Anschlussbuchse für externen Lautsprecher (als Option erhältlich)

Stromversorgung: 13.8V DC (max. 5 A)

Anzeige der Spannung im Display

Sensationell kleine Abmessungen B x H x T: 105 x 25 x 105 mm

Lieferumfang:
Mikrofon
Mikrofonhalterung
Stromkabel mit Zigarettenanzünder-Stecker
Mobilhalterung
Anleitung (Deutsch / Englisch / France)
Gewicht: 0.28 kg

UHF Monoband-Mobilfunkgerät mit sensationell kleinen Abmessungen !

Aufgrund des Minigehäuse hat das Gerät eine maximale Sendeleistung von 17 Watt.

Technische Daten:

Frequenzbereich 400-470 MHz

199 Speicherplätze (per PC programmierbar)

Sendeleistung umschaltbar Low: 5 Watt / Middle: 10 Watt / High: ca. 15 - 17 Watt

Betriebsart FM (wide / narrow umschaltbar 16K0F3E / 11K0F3E)

CTCSS / DCS

Kanalraster wählbar 2.5 / 5 / 6.25 / 10 / 12.5 / 20 / 25 / 30 / 50 / kHz

programmierbare Relaisablage

Rauschsperre regelbar (10 Empfindlichkeitsstufen)

Monitorfunktion

Scan Funktion (inkl. CTCSS & DCS Scan)

BCLO Funktion

Time-Out Timer Funktion

APO Funktion

Mikrofon-Verstärkung regelbar (Mic Gain Setup)

Reset Funktion

Mikrofonanschluss: Mikrofon fest mit Gerät verbunden

PL-Antennenanschluss

3.5mm Anschlussbuchse für externen Lautsprecher (als Option erhältlich)

Stromversorgung: 13.8V DC (max. 5 A)

Anzeige der Spannung im Display

Sensationell kleine Abmessungen B x H x T: 105 x 25 x 105 mm

Lieferumfang:
Mikrofon
Mikrofonhalterung
Stromkabel mit Zigarettenanzünder-Stecker
Mobilhalterung
Anleitung (Deutsch / Englisch / France)
Gewicht: 0.28 kg

• DESCRIPTION

• Frequencies: 144 – 146 MHz / 430 – 440 MHz
• Power of transmission: 25, 15 and 5 W
• Operates in V-U, U-V, V-V and U-U
• 200 programmable memory channels
• Broad band with 25 kHz and narrow band with 12.5 kHz
• Frequency jumps: 2.5 kHz, 5 kHz, 6.25 kHz, 10 kHz, 12.5 kHz, 20 kHz, 25 kHz, 30 Khz and 50 kHz
• 51 CTCSS + 1 programmable / 512 DCS, with scanner function
• Microphone in DTMF, multifunction
• Signage of 5 tones for data transfer, alarm, call to all users, remote usability and remote activation
• DTMF-ANI for the automatic recognition of calls
• TFT LCD screen with rotation of 180 degrees
• Alloy housing for heat dissipation
• Radio amateur mode for different operating requirements
• Distribution of the keys in a reasonable and convenient way to handle the transceiver
• Configuration of the individualized bandwidth for each channel
• Alphanumeric memories
• Includes 5 individualized tone for each channel, rejecting unwanted calls from other transceivers
• Several scanning functions
• Includes CTCSS and DCS tone scanner
• Smart menu control and programmable by PC
• Includes protection against overvoltage
• Setting the brightness of the LCD screen
• Color screen
• Automatic ignition function
• Transceiver keyboard lock function
• Function of blocking of the keys of the microphone
• Optional scrambler (secrephone)
• Small size
• Dimensions: 124 (width) x 163 (bottom) x 39 (high) mm
• Weight: 640 gr.

The pack includes:Anytone AT-778UV, multifunction microphone, support for the radio, screws and nuts, power cord and. instruction manual in Spanish and English.
